درایو موتور آسانسور نمایندگی اشنایدر الکتریک تهران مدل Schneider ATV71LD17N4Z

Altivar Lift

Variable speed drive

ATV71

Asynchronous motors
Synchronous motors

Lift

With heat sink

With integrated 7-segment display terminal

Integrated

3 phases

380…480 V – 15…10 %

323…528 V

50…60 Hz – 5…5 %

7.5 kW, 3 phases at 380…480 V

10 hp, 3 phases at 380…480 V

27 A for 380 V 3 phases 7.5 kW / 10 hp
22.2 A for 480 V 3 phases 7.5 kW / 10 hp

17.8 kVA at 380 V 3 phases 7.5 kW / 10 hp

22 kA for 3 phases

17.6 A at 4 kHz 380 V 3 phases 7.5 kW / 10 hp
14 A at 4 kHz 460 V 3 phases 7.5 kW / 10 hp

23.9 A for 2 s 3 phases / 7.5 kW / 10 hp

0…599 Hz

12 Ohm

8 kHz

1…16 kHz adjustable

1…100 for asynchronous motor in open-loop mode, without speed feedback
1…50 for synchronous motor in open-loop mode, without speed feedback
1…1000 for asynchronous motor in closed-loop mode with encoder feedback

+/- 0.01 % of nominal speed in closed-loop mode with encoder feedback 0.2 Tn to Tn
+/- 10 % of nominal slip without speed feedback 0.2 Tn to Tn

+/- 5 % in closed-loop mode with encoder feedback
+/- 15 % in open-loop mode, without speed feedback

170 %, +/- 10 % for 60 s
220 %, +/- 10 % for 2 s

30 % without braking resistor
<= 150 % with braking or hoist resistor

Flux vector control without sensor, ENA (energy Adaptation) system
Flux vector control with sensor, standard
Voltage/frequency ratio – Energy Saving, quadratic U/f
Flux vector control without sensor, standard
Voltage/frequency ratio, 5 points
Flux vector control without sensor, 2 points
Voltage/frequency ratio, 2 points

Vector control with sensor, standard
Vector control without sensor, standard

Adjustable PI regulator

Not available in voltage/frequency ratio (2 or 5 points)
Automatic whatever the load
Adjustable
Suppressable

1 LED (red) for drive voltage

<= power supply voltage

Electrical between power and control

Without mounting kit: 1 wire(s)IEC cable at 45 °C, copper 90 °C / XLPE/EPR
Without mounting kit: 1 wire(s)IEC cable at 45 °C, copper 70 °C / PVC
With an IP21 or an IP31 kit: 3 wire(s)IEC cable at 40 °C, copper 70 °C / PVC
With a NEMA Type1 kit: 3 wire(s)UL 508 cable at 40 °C, copper 75 °C / PVC

Terminal, clamping capacity: 2.5 mm², AWG 14 (AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1…LI6, PWR)
Terminal, clamping capacity: 6 mm², AWG 8 (L1/R, L2/S, L3/T, U/T1, V/T2, W/T3, PC/-, PO, PA/+, PA, PB)

3 N.m, 26.5 lb.in (L1/R, L2/S, L3/T, U/T1, V/T2, W/T3, PC/-, PO, PA/+, PA, PB)
0.6 N.m (AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1…LI6, PWR)

Internal supply for reference potentiometer (1 to 10 kOhm): 10.5 V DC +/- 5 %, <10 A, protection type: overload and short-circuit protection
Internal supply: 24 V DC (21…27 V), <200 A, protection type: overload and short-circuit protection

2

AI2 software-configurable voltage: 0…10 V DC 24 V max, impedance: 30000 Ohm, resolution 11 bits
AI1-/Al1+ bipolar differential voltage: +/- 10 V DC 24 V max, resolution 11 bits + sign
AI2 software-configurable current: 0…20 mA, impedance: 242 Ohm, resolution 11 bits

2 ms +/- 0.5 ms (LI6)if configured as logic input – discrete input(s)
2 ms +/- 0.5 ms (LI1…LI5) – discrete input(s)
2 ms +/- 0.5 ms (AI1-/Al1+) – analog input(s)
2 ms +/- 0.5 ms (Al2) – analog input(s)

R1A, R1B, R1C 7 ms, tolerance +/- 0.5 ms for discrete output(s)
R2A, R2B 7 ms, tolerance +/- 0.5 ms for discrete output(s)
AO1 2 ms, tolerance +/- 0.5 ms for analog output(s)
<= 100 ms in STO (Safe Torque Off)

+/- 0.6 % (AI1-/Al1+) for a temperature variation 60 °C
+/- 0.6 % (AI2) for a temperature variation 60 °C
+/- 1 % (AO1) for a temperature variation 60 °C

+/- 0.15 % of maximum value (AI1-/Al1+, AI2)
+/- 0.2 % (AO1)

1

AO1 software-configurable voltage: 0…10 V DC, impedance: 470 Ohm, resolution 10 bits
AO1 software-configurable current: 0…20 mA, impedance: 500 Ohm, resolution 10 bits
AO1 software-configurable logic output 10 V 20 A

2

Configurable relay logic: (R1A, R1B, R1C) NO/NC – 100000 cycles
Configurable relay logic: (R2A, R2B) NO – 100000 cycles

3 mA at 24 V DC for configurable relay logic

5 A at 250 V AC on resistive load – cos phi = 1 – L/R = 0 ms (R1, R2)
5 A at 30 V DC on resistive load – cos phi = 1 – L/R = 0 ms (R1, R2)
2 A at 250 V AC on inductive load – cos phi = 0.4 – L/R = 7 ms (R1, R2)
2 A at 30 V DC on inductive load – cos phi = 0.4 – L/R = 7 ms (R1, R2)

7

Programmable (LI1…LI5)24 V DC, with level 1 PLC – 3500 Ohm
Switch-configurable (LI6)24 V DC, with level 1 PLC – 3500 Ohm
Switch-configurable PTC probe (LI6) – 0…6 probes – 1500 Ohm
Safety input (PWR)24 V DC – 1500 Ohm

Positive logic (LI6)if configured as logic input, < 5 V (state 0), > 11 V (state 1)
Negative logic (LI6)if configured as logic input, > 16 V (state 0), < 10 V (state 1)
Positive logic (LI1…LI5), < 5 V (state 0), > 11 V (state 1)
Negative logic (LI1…LI5), > 16 V (state 0), < 10 V (state 1)
Positive logic (PWR), < 2 V (state 0), > 17 V (state 1)

Automatic adaptation of ramp if braking capacity exceeded, by using resistor
Linear adjustable separately from 0.01 to 9000 s
S, U or customized

Overheating protection: drive
Thermal protection: drive
Short-circuit between motor phases: drive
Input phase breaks: drive
Overcurrent between output phases and earth: drive
Overvoltages on the DC bus: drive
Break on the control circuit: drive
Against exceeding limit speed: drive
Line supply undervoltage: drive
Line supply overvoltage: drive
Against input phase loss: drive
Thermal protection: motor
Motor phase break: motor
Power removal: motor

3535 V DC between earth and power terminals
5092 V DC between control and power terminals

> 1 mOhm 500 V DC for 1 minute to earth

Display unit: 0.1 Hz
Analog input: 0.024/50 Hz

CANopen
Modbus

1 RJ45 (on front face) for Modbus
1 RJ45 (on terminal) for Modbus
Male SUB-D 9 on RJ45 for CANopen

2-wire RS 485 for Modbus

RTU for Modbus

9600 bps, 19200 bps for Modbus on front face
4800 bps, 9600 bps, 19200 bps, 38.4 Kbps for Modbus on terminal
20 kbps, 50 kbps, 125 kbps, 250 kbps, 500 kbps, 1 Mbps for CANopen

8 bits, 1 stop, even parity for Modbus on front face
8 bits, odd even or no configurable parity for Modbus on terminal

No impedance for Modbus

1…247 for Modbus
1…127 for CANopen

Slave CANopen

Communication card for Modbus TCP
Communication card for Fipio
Communication card for Modbus/Uni-Telway
Communication card for Modbus Plus
Communication card for Ethernet/IP
Communication card for DeviceNet
Communication card for Profibus DP
Communication card for Profibus DP V1
Communication card for Interbus-S
Communication card for CC-Link
Interface card for encoder
I/O extension card
Controller inside programmable card
Overhead crane card

Vertical +/- 10 degree

Electrostatic discharge immunity test level 3 conforming to IEC 61000-4-2
Radiated radio-frequency electromagnetic field immunity test level 3 conforming to IEC 61000-4-3
Electrical fast transient/burst immunity test level 4 conforming to IEC 61000-4-4
1.2/50 µs – 8/20 µs surge immunity test level 3 conforming to IEC 61000-4-5
Conducted radio-frequency immunity test level 3 conforming to IEC 61000-4-6
Voltage dips and interruptions immunity test conforming to IEC 61000-4-11

2 conforming to EN/IEC 61800-5-1

IP20 on upper part without blanking plate on cover conforming to EN/IEC 61800-5-1
IP20 on upper part without blanking plate on cover conforming to EN/IEC 60529
IP21 conforming to EN/IEC 61800-5-1
IP21 conforming to EN/IEC 60529
IP41 on upper part conforming to EN/IEC 61800-5-1
IP41 on upper part conforming to EN/IEC 60529
IP54 on lower part conforming to EN/IEC 61800-5-1
IP54 on lower part conforming to EN/IEC 60529

1.5 mm peak to peak (f= 3…13 Hz) conforming to EN/IEC 60068-2-6
1 gn (f= 13…200 Hz) conforming to EN/IEC 60068-2-6

15 gn for 11 ms conforming to EN/IEC 60068-2-27

55.6 dB conforming to 86/188/EEC

5…95 % without condensation conforming to IEC 60068-2-3
5…95 % without dripping water conforming to IEC 60068-2-3

-10…50 °C (without derating)

-25…70 °C

<= 1000 m without derating
1000…3000 m with current derating 1 % per 100 m

EN 55011 class A group 2
EN 61800-3 environments 2 category C3
IEC 60721-3-3 class 3C1
EN 61800-3 environments 1 category C3
EN/IEC 61800-5-1
IEC 60721-3-3 class 3S2
UL Type 1
EN/IEC 61800-3

C-Tick
CSA
NOM 117
UL
GOST

CE
